Model 1040SI
Model 1040SI
The 1040SI is the only drop spreader specifically designed to fit the dump box of a utility terrain vehicle. Driven by a 12 Volt, 1/4HP motor, this model fits into a 42 inch x 42 inch RTV / UTV deck, vehicles such as the Kubota RTV 1100 or John Deere Gator.
Driven by an electric 1/2HP motor.
Specifications
12 Volt Electric Drive
Capacity: 10 Cubic Feet
Spreading Width: 40 inches
Estimated Spreading Distance: 8.5 km
Set up with sand distributor drum
Weight: 300 lbs
Dimensions: 47 inches wide x 30 inches high x 58 inches long
Downloads
Key Features
Serviceable Bearings
Finger Bar
A unique polymer finger bar has a flexible memory in cold weather and retains its shape. The bar defines pressure and helps release an even quantity of de-icing material as seen with the cross hatch pattern when material is dropped.
Sand / Salt Drum
The rotating distributor drums spread de-icing material in an even and consistent cross hatch pattern. De-icing material can then "creep" and spread out which results in an efficient use of material.
Spread Pattern
The rotating distributor drums spread de-icing material in an even and consistent cross hatch pattern.
Agitator Bar
The agitator bar rotates in the hopper to help keep salt and sand from bridging or clumping. The bar ensures the material passes through to the drum and then to the ground for an even application.
Tension Lever Assembly
The assembly regulates the rate of flow for different types of material (i.e.: fine sand vs coarse salt). The lever allows for fine tuning of the rate of flow of material.
12 Volt 1/4HP DC Electric Motor
The 12 Volt 1/4HP DC electric motor and reducer drives the 440E. The epoxy paint protects the unit from salt brine/slushy environment.
Wiring Kit
Complete braided wiring kit is included with Electric models.
Variable Speed Control
Variable speed control allows an operator to control distribution quantity.
